Place of Origin:
China
Brand Name:
YUYANG
Model Number:
YYE-041
70±5%RH(adjustable) Concrete Carbonation Test Chamber 20%±2% 2KW
Product Description:
Concrete carbonation testing cabinet is a sealed box. Placing the specimen on cabinets partitions, then set temperature, relative humidity, carbon dioxide concentration by controller to ensure the box constant temperature and humidity, and constant carbon dioxide concentration.
The concrete carbonation chamber is the concrete carbonation test equipment.
1.Concrete carbonation chamber adopt imported carbon dioxide sensor, the sensor uses the principle of infrared detection,
2. combined with the advanced digital measurement,
3.with high precision, long operating life;
4.Temperature and humidity sensor adopts domestic advanced integrated sensor module added multi - channel intelligent instruments.
5.The concrete carbonation chamber with high control accuracy, simple operation.
6.Box temperature, humidity, concentration can intuitively digital display and timing print record.
Concrete Carbonation Test Chamber |
||||||||||
| Specification | YYE-041-100UA | YYE-041-150UA | YYE-041-250UA | YYE-041-500UA | YYE-041-010UA | |||||
| Workroom Sizes W*D*H (cm) | 50x40x50 | 50x50x60 | 60x60x70 | 80x70x90 | 100x100x100 | |||||
| Inner chamber volume(V) | 100L | 150L | 252L | 504L | 1000L | |||||
| Outer dimension W*D*H(cm) | 98x95x160 | 98x105x170 | 108x112x180 | 128x125x200 | 148x155x210 | |||||
| Packing Size | 113x110x175 | 113x120x185 | 123x127x195 | 133x140x215 | 163x160x225 | |||||
| G.W(kg) | 360 | 390 | 450 | 480 | 620 | |||||
| Temperature Range | RT+10℃-300℃ | |||||||||
| Temperature Fluctuation | ≤±0.5°C(standard)/≤±0.2°C(optional) | |||||||||
| Temperature Evenness | ≤±2°C | |||||||||
| Temperature Deviation | ≤1°C | |||||||||
| Accuracy | 0.1°C,1.5%R.H (standard)/0.01℃,1.5%R.H(optional) | |||||||||
| Humidity Range | 20%~98%R.H/10%~98%R.H(optional) | |||||||||
| Humidity Deviation | ±2% R.H | |||||||||
| Temperature Rise Speed | 0.5°C~5°C/min(programmable) | |||||||||
| Time needed for heating | RT°C~250°C≤60min | |||||||||
| The machine noise | 72 dB(A) | |||||||||
| Load on the largest | 100kg,≤20kg/layer | 150kg,≤26kg/layer | 260kg,≤30kg/layer | 260kg,≤40kg/layer | 300kg,≤60kg/layer | |||||
| Equipment installed power | ~3.25KW | ~3.55KW | ~3.95KW | ~5.5KW | ~6.25KW | |||||
| material | Inner chamber:# SUS 304 stainless steel | The outer wall:A3 carbon steel plate with plastic spray/#SUS304 | ||||||||
| Wind Cycling Way | Centrifugal fan forced air circulation | |||||||||
| Heater | Nickel chrome heating wire heater | |||||||||
| Humidifier | Semi-closed steam and wet | |||||||||
| Water Suplying Way | Automatic cycling water supply | |||||||||
| Controller | Japan OYO/Korea Temi | |||||||||
| Standard Accessoriesparts | 1 Observe window(double-deck cavity toughened glass),50mm testing hole,PL internal bulbs,partition plate,dry and wet ball gauze,3 fuses,1 power line | |||||||||
