Automotive 500W NF P92-505 Flammability Testing Equipment

Thermal Radiant Melt Drop Tester Melt Flammability Tester

NF P92-505 , EU 95/28/EC Thermal Radiant Melt Drop Tester Melt Flammability Tester

Description:

Thermal Radiation Melt Drop Tester NF P92 For Building Materials can be used for more than 5mm thickness of rigid and elastic material performance evaluation, and it is developed according to flame test standard NF P92-501.

Thermal Radiation Melt Drop Tester NF P92 For Building Materials to provide 30KW / m2 heat radiation, which may lead to volatile flammable gas sample and triggered the combustion of volatile gases, and at the same time to observe the state of the flame spread through the material and estimate combustion heat release data. Suitable for railway vehicle test radiation test methods of fire-resistant material.

Standard:

NF P92-505 Dripping test with electrical radiator, used for melting materials
EU 95/28/EC
ECE R118 Annex 7 Test to determine the melting behavior of materials

Application:

Building Materials
Rail
Automotive Interior

Features:

1, Stainless steel test cabinet, the inner wall is flame-resistant material with a transparent viewing window;

2, Stainless steel tubular inlet device, equipped with filtration devices shield for indoor sources;

3, 45° of the test stand, equipped with stainless steel foot instructions to calculate the distance of flame spread;

4, Heat radiation device can provide 30KW / m2 heat flux;

5, The power controller controlling the radiation output, adjustable heat radiation;

6, The heat radiating panel display device operating power value, eliminating frequent calibration procedure;

7, The stainless steel burner can ignite the combustible gas automatically;

8, The imported needle valve can control the upper and lower burner flame height, with a flame height measuring;

Specification:
