1.0-3.2mm Pcb Separator Machine Led Strip Cutting Laser Depaneling

Pcb Separator Separating Cutter Led Strip Cutting Machine Laser Depaneling

Application

The upper and lower two knives are a group to form a cutting unit. They are groups A, B, C and C. The whole cutting process is divided into three stages. The blades in group A cut 40% of the circuit board, and then the BLADES in group B run over the groove cut by the blades in group A again to complete 40% of the cutting quantity. Finally, the blades in group C cut the last 20% and polished the circuit board. Therefore, the stress generated in the cutting process is reduced by more than 80% compared with the traditional cutting way, and the edge of the circuit board is smooth and smooth, and the board is very flat and not twisted. It is the only machine on the market that can guarantee the aluminum plate does not deform after cutting

Features

1. The shaft of the knives( top and bottom) is design to be an an integral whole, it is convenient to install, pick and place.
2. This machine adopts computer screen control with a counting device which can be preset production. Gap of the cutting tool displayed by the display screen directly.
3. All the v-cut pcb board can be cut by this machine.
4. Using the machine to cut, reduce stress, prevent the solder joint cracking.
5. Pcb board is cut by multiple cutters which can cut several board once.
6. The machine top cutter wheel can be slightly adjust:0-5mm.
7. The distance between the knives can be adjusted, and it is suitable to cut single pcb board within width 15-20mm.
8. Blade is made of SKH51 high speed steel with long service life and wear resistance.
9. Cutting speed can be set and conveniently adjusted by turn-knob.
10. Install conveyer belt, pcb board which is cut can be sent out directly, then docking with the next machine and reducing the times of artificial pick and place. This machine can cut LED panel, fiberboard, aluminum board (more than 400mm ) and special board.
