Place of Origin:
China
Brand Name:
YUYANG
Certification:
GB/T4802.1-2008, DIN 53863.2
Model Number:
YY824
Martindale Testing Machine Simulating Daily Use For Truly Evaluating Textile Durability
Description:
The UV Aging Test Lamp is a reliable device for conducting sunlight resistance tests on non - metallic materials in industrial applications. It is applicable to materials used in the chemical, pharmaceutical,
and biotechnology industries. Constructed with advanced technology, this lamp can simulate sunlight, humidity, and dew conditions. It can lead to issues like bleaching, loss of chemical stability, and powdering
in the tested materials, enabling manufacturers to ensure the quality and reliability of their products.
Working principle
The working principle of the Martindale tester lies in the fact that it subjects a textile sample to a rubbing motion with a specific abradent. The sample is under a controlled pressure environment, and the rubbing
direction is continuously altered during the test. As the test goes on, the abradent gradually wears away the fibers of the textile. The evaluation of the textile's abrasion and pilling resistance is achieved by comparing
the worn - out state of the sample with predefined standards.
Standard:
GB/T4802.1-2008, DIN 53863.2
Specifications:
1. Pilling trajectory: circular track of 40mm diameter
2. Brush with adjustable height: 2~12mm
3. Pressure for specimen:
Chemical Fiber fabric: 590cN
Combed wool fabric:780cN
Crude wool fabric 490cN
4. Specimen size: 112.8mm with area 100cm2
5. Rubbing times: 1~9999S
6. Rubbing speed: 60 RPM
7. Power: AC220V 50Hz 60W
8. Dimension: 540*250*345 mm (L*W*H)
9. Weight: 35KG
10. Accessories: power line 1pcs
