Place of Origin:
China
Brand Name:
YUYANG
Certification:
ISO, CE
Model Number:
YYE-009
Environmental Test Chamber Humidity Resistance in Electronics Electrical Appliances and More
Application:
This machine test material heat, cold, dry resistance, humidity resistance. Suitable for electronics, electrical appliances, communications, instrumentation, vehicles, plastic products, metal, food, chemical, building materials,
aerospace and other products.
| Model | YYE009-50L |
| Inner size: WHD(cm) | 35*36*40 |
| Temperature range | -20ºC-+150ºC |
| Temp analytic accuracy/ uniformity |
0.1ºC/±2.0ºC |
| Temperature Fluctuation | ±0.5ºC |
| Humidity analytic accuracy/ Humidity control accuracy | ±0.1%; ±2.5% |
| Heat; cooling time | Heat up about 3.0°C/min ; Cooling about 1.0°C/min |
| Inner and outer materials | SUS#304 Stainless steel for inner chamber ; Carton Advanced cold plate nano paint for outer |
| Cooling system | Air cooling/single segment compressor(-20°C) |
| Protection devices | Fuse switch, compressor overload switch, refrigerant high and low pressure protection switch, super humidity over-temperature protection switch, fuse, failure warning system |
| Compressor | Original France "Tecumseh" brand |
| Controller | TEMI South Korea |
| Power | AC220V 50/60Hz & 1 |
| weight (kg) | 120kg |
